SPECIFICATIONS

Brand Name: Bymaocar

Material: Stainless steel

Use: Embroidery

About this item

• Sewing Assistant: As a skilled helper in sewing, this pure copper brushless motor and leather skiving machine can be easily started without requiring too many tools and operating skills, helping you complete various sewing tasks, enriching your life and adding fun.
• Outstanding Performance: This leather skiving machine and servo motor kit is equipped with an independent stepless speed lever (500-4500rpm) with a fast sewing speed of 100 stitches/min. Compared to other motors, this pure copper brushless motor can respond faster to changing workloads and speed requirements, with a 30% increase in work efficiency, making it your ideal choice.
• Stable Performance: The centripetal ball bearing design ensures the stability of the machine during operation, making it run smoothly and with less noise.
• High Efficiency: The unique automatic sharpening device can sharpen the knife while the machine is working, keeping the round knife sharp and greatly improving work efficiency.
• Good Applicability: This Leather skiving machine+servo motor sewing machine has a maximum single shovel width of 1.57 inches and is equipped with three different specifications of presser feet (1.57, 0.98, 0.59 inches) to meet the skiving needs of different materials.

Product Description

Specification

Servo Motor:

• Color: Silver, White
• Material: Aluminum, Plastic, Copper, Magnet Steel
• Motor Type: Pure Copper Brushless Motor (99.5% Purity)
• Power: 600W
• Torque: 1.5-5NM
• Pole-pair Number: 6
• Plug Type: US Standard
• Voltage: 110V, 50/60HZ
• Continuous Working Hours: Over 72 Hours
• Speed: 500-4500rpm
• Sewing Speed: 100 Stitches/min
• Cable Length: 1.81m/5.94ft
• Foot Pedal Size: 8*7*3.6cm/3.2*2.8*1.4in
• Controller Size: 18.7*6*15.9cm/7.4*2.4*6.3in
• Base Thickness: 1.12cm/0.44in
• Package Size: 31.4*28.5*21cm/12.4*11.2*8.3in
• Product Size: 25.5*13.5*15cm/10*5.3*5.9in
• Net Weight: 3.95kg/8.7lbs
• Gross Weight: 4.35kg/9.6lbs

Leather Skiving Machine:

• Color: White
• Material: Cast Iron
• Process: Plastic Spraying
• Operation Mode: Electric
• Max. Single Shovel Width: 40mm/1.57in
• Presser Foot Specification: 40, 25, 15mm/1.57, 0.98, 0.59in
• Product Size: 56*36*41cm/22.05*14.17*16.14in
• Package Size: 62*42*42cm/24.41*16.54*16.54in
• Gross Weight: 41.45kg/91.38 lbs
• Net Weight: 41kg/90.39 lbs
