ANNKE 8CH 4K IP Camera Security System 265+ 8MP Two Way Audio Video CCTV 4MM Support 256G Card IP67
ANNKE 8CH 4K IP Camera Security System 265+ 8MP Two Way Audio Video CCTV 4MM Support 256G Card IP67
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: ANNKE
Cable Length: 18m
Certification: CE
High-concerned chemical: None
IR Cut Filter: YES
Image sensor: 1/2.5" Progressive Scan CMOS
Min.Illumination: 0.01
Model Number: N48PAW-I91DF*4/8
Night Vision Distance: Up to 100ft/30m
Number of Infra-Red LEDs/Lens: 1pcs/2.8mm
Operating Power: POE
PCS of Camera: 4PCS,8PCS
Resolution: 8MP
Smart home platform: None
TV System: NTSC,PAL
Type 1: security camera system 4k
Type 2: security camera system outdoor
Type 3: poe camera 4 k
Type 4: ip camera 8mp 4k
Type 5: 8mp cctv camera
Type 6: security camera kit
Video Compression: H.264+/H.264/H.265/H.265+/MPEG4
Video Input: 8 Channel
Video Output: HDMI Up to 4K,VGA Up to 1080P
Wide Dynamic Range/DNR: Digital WDR/3 DNR
Main Features
★ 4K smart dual light turret network camera
★ 4mm@F1.6 lens brings everything back to life
★ Efficient H.265+ compression technology
★ Motion detection 2.0 with human & Vehicle Detection
★ Clear day and night vision with 3D DNR and 120DB WDR
★ Built-in microphone for real-time audio security
★ Support on-board storage up to 512 GB (SD card slot)
★ IP67 Dust and Waterproof Rating
★ Support PoE &DC12V
[Unrivaled 4K in All Environments] This 8mp outdoor security camera has exceptional 4K UHD images realized, 120 dB true WDR, 3D DNR, BLC & HLC tech; 4mm lens provides diagonal 96° view angle. Ultra HD pixels make EXIR 2.0 Night Vision with Smart IR up to 100ft
[More Videos & Less Bandwidth with H.265+] The leading H.265+ compress tech enables the 4K system to record longer videos & consume less bandwidth without losing 4K quality, saving you up to 75% storage space.
[Easy Plug & Play PoE Setup] Plug the 4K network video recorder to an outlet & the router. Connect the camera to the NVR with just a network cable, no power cables needed for cameras. Ease the complex wiring project.
[IP67 Weatherproof & IK08 Vandal-Proof] The IP67 weatherproof rating & corrosion-resistance all-metal housing ensure the 8mp outdoor ip camera works extremely in all extremely weather (-22 °F – 140 °F).
8CH NVR + 4Pcs Camera
1 X NVR
1 X USB Mouse
1 X Power Adapter
1 X 1M network cable
1 X 1.8M HDMI cable
4 X Camera
2 X 60ft/18m Ethernet Cable
2 X 100ft/30m Ethernet Cable
4 X Mounting Screws Bag
1 X User's Manual
8CH NVR + 8Pcs Camera
1 X NVR
1 X USB Mouse
1 X Power Adapter
1 X 1M network cable
1 X 1.8M HDMI cable
8 X Camera
4 X 60ft/18m Ethernet Cable
4 X 100ft/30m Ethernet Cable
8 X Mounting Screws Bag
1 X User's Manual
|
NVR |
||
|
Video & Audio |
Decoding Format |
H.264+/H.264/H.265/H.265+ |
|
IP Video Input |
8CH PoE |
|
|
Video Output |
HDMI up to 4K (3840 × 2160), VGA up to 1080p(1920 × 1080) |
|
|
Audio Input/Output |
1/1 RCA |
|
|
Incoming/outgoing Bandwidth |
80/80 Mbps |
|
|
Max Recording Resolution |
Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
|
|
Max Playback Resolution |
Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
|
|
Max Playback Channel |
8CH |
|
|
Max Playback Capacity |
1-ch@12 MP(4096 X 3072) (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) |
|
|
Hard Drive |
HDD |
1 SATA Interface |
|
HDD Capacity |
Up to 8 TB Capacity |
|
|
External Interface |
Network Interface |
1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
|
PoE |
8, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at |
|
|
USB interface |
USB 2.0*2 |
|
|
Smart Function |
Deep learning |
8-ch Human and vehicle targets detection(Need IP camera support) |
|
4-ch Human and vehicle targets detection(IP camera does not need to support this function but the resolution cannot exceed 4MP) |
||
|
Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting |
|
|
General |
Operating Power |
DC 48 V |
|
Power Consumption |
≤10 W (Without HDD and PoE) |
|
|
PoE: Max 25.5 W for Single Port |
||
|
Working Temperature |
14 °F ~ 131 °F/-10 °C ~+55 °C |
|
|
Dimensions (W X H X D) |
12.4” X 9.4” X 1.9”/315 X 240 X 48 mm |
|
|
Weight (Without Hard Disk) |
2.2 lbs/1 kg |
|
|
IP Camera |
||
|
Camera |
Image Sensor |
1/2.4" Progressive Scan CMOS |
|
Max resolution |
3840*2160(8MP) |
|
|
Main Stream |
50 Hz: 12.5fps@3840*2160, 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
|
|
Substream |
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) |
|
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 |
|
|
Video Bitrate |
32 Kbps - 16 Mbps |
|
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/ AAC-LC |
|
|
Audio Input |
Built-in Microphone, record with audio |
|
|
Lens |
4 mm |
|
|
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
|
|
Angle of View |
Horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96° |
|
|
Supplement Light Type |
Smart Dual-Light, IR, White Light |
|
|
Supplement Light Range |
Up to 30 m |
|
|
Motion detection 2.0 |
Supoort, include Human & Vehicle detection |
|
|
Image Enhancement |
BLC, HLC, 3D DNR |
|
|
Wide Dynamic Range |
120 dB WDR |
|
|
Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP |
|
|
API |
Open Network Video Interface Version (Profile S, Profile T, Profile G) |
|
|
Region of Interest (ROI) |
1 fixed region for main stream |
|
|
Privacy Mask |
4 programmable polygon privacy masks |
|
|
General Function |
Rotate mode, mirror, password protection, remote access |
|
|
Ethernet |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
|
General |
Housing |
Metal & Plastic |
|
Color |
White |
|
|
Storage |
Built-in microSD/SDHC/SDXC Slot, up to 512 GB |
|
|
Hardware Reset |
Yes |
|
|
Operating Power |
DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W |
|
|
Operating Temperature |
-22 °F – 140 °F/-30 °C – 60 °C |
|
|
Indoor/Outdoor Use |
Indoor/Outdoor |
|
|
Interface Protection |
IP67 & IK08 |
|
|
Dimension (L X W X H) |
Ø121.4 mm × 97.6 mm (Ø4.78" × 3.84") |
|
|
Weight |
1.2 lb./550 g |
|
